Newpowa 50W Watts 12V Mono Solar Panel Off Grid Solar Charge Kit 50 Watt 12 Volt Solar Panel+10A PWM Charge Controller+6ft Extension Cable for RV Marine Car Motorcycle Battery Charge Kit

Price: $84.50
(as of Jun 26, 2024 11:48:01 UTC – Details)

Product Description

Key Features

Easy Installine

The panel comes with four easy mounting holes with a diameter of 7mm, and two grounding holes with a diameter of 5mmWith pre-attached 3ft solar connector cable, add 1ft extension cable, which can be quickly connected to other itemsCompatible with the Newpowa z-bracket, tilt adjustable mount, and pole/wall bracket, the panel can be installed for various applications

Durable

Heavy-duty anodized frame with pre-drilled holes for mountingRugged design to withstand high winds (2400Pa), hail, and snow load (5400Pa)Durable TPT back sheet – dissipates heat to insure better panel performance and lifespan

Versatile

Supported by a number of mounting options, the panel can adapt flat surface mounts (Z-bracket, tilt-adjustable bracket) and pole/wall installationDespite the smaller wattage output, the panel can be used for many applications such as gate openers, water pumps, SUVs, security systems, Vans, etc.

Specifications

Dimension: 29.13*14.37*1.18 inchesWeight: 9.3 lbs Max Power Output(W): 50WVoltage MPP Vmp(V): 19.06VCurrent MPP Imp(A): 2.63AVoltage Open Circuit Voc(V): 21.82VShort Circuit Current Isc(A): 2.77A

FAQ

1: Does a Solar Panel produce full power?

A: In most cases, it is normal for a solar panel to not be able to provide its full nominal power.

Factors affecting the performance of solar panels:

Peak Sun Hours， Sunlight Angle， Operating Temperature， Installation Angle， Panel Shading， Adjacent Buildings Etc…

2: How to test a solar panel?

A: The ideal conditions: Test in the noon, under a clear sky, panels should be at 25 degrees tilted towards the sun, and the battery is at a low state/less than 40% SOC. Disconnect the solar panel from any other loads, using a multimeter to test the panel’s current and voltage.

3: How does temperature affect solar panel efficiency?

A: Solar panels are generally tested at about 77°F/25°C and are rated to perform at peak efficiency between 59°F/15°C and 95°F/35°C. Temperature going up or down will change the efficiency of the panels. For example, if the temperature coefficient of power is -0.5%, then the panel maximum power will be reduced by 0.5% for every 50°F/10°C rise.

4: How to install our solar panels using different brackets?

A: There are mounting holes on the panel frame for easy installation using a variety of brackets. Most compatible with Newpowa’s Z-mount, tilt-adjustable mount, and pole/wall mount, making panel mounting suitable for a variety of applications.

5: Can I connect different solar panels together?

A: Though mixing different solar panels is not recommended, the mismatch can be achievable as long as each panel’s electrical parameters (voltage, current, wattage) are carefully considered.

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.6 out of 5 stars
390

4.6 out of 5 stars
437

4.7 out of 5 stars
420

4.4 out of 5 stars
30

4.5 out of 5 stars
492

4.6 out of 5 stars
757

Price

— $35.59$35.59 $46.79$46.79 $79.99$79.99 $79.99$79.99 $229.99$229.99

MAX Watt
20W 25W 30W 70W 100W 250W

Cell Type
Monocrystalline Monocrystalline Monocrystalline Monocrystalline Bifacial Monocrystalline Monocrystalline

Dimensions (in.)
14.41 x 13.58 x 1.10 18.11 x 13.39 x 0.91 21.54 x 13.58 x 1.10 28.74 x 20.87 x 1.18 38.58 x 20.87 x 1.18 54.72 x 34.45 x 1.38

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.4 out of 5 stars
57

4.6 out of 5 stars
380

4.6 out of 5 stars
266

4.0 out of 5 stars
65

4.6 out of 5 stars
108

4.7 out of 5 stars
248

Price

$36.99$36.99 $11.99$11.99
— $46.97$46.97 $9.99$9.99 $7.99$7.99

Accessories
20in width heavy duty angle adjustable tilt mount A set of Z bracket include all bolts and screws 21.6in heavy duty single arm pole/wall bracket Negative ground 15A 12V MPPT charge controller Extension cable with male/female connectors used to connect solar panel and charge controller Solar Branch Connector

【New Design】Maximum power (Pmax): 50W Voltage at Pmax (Vmp):19.06V Current at Pmax (Imp): 2.63A. Higher cell efficiency by using 9 busbars technology. Compared with 5BB solar panel cells, the 9BB 166mm solar cell has a better and longer lifespan.
【Durable & Waterproof】IP65 waterproof, the high-transparent, low iron tempered glass and aluminum frame can stand with high wind (2400Pa), hail and snow load (5400Pa)
【Easy Installation】Pre-attached 3ft wire with solar connectors and mounting holes ready(Mounts for Purchase Separately)
【Versatile】Perfect for off-grid applications, such as gate openers, fences, Security Cameras and lights. Charging the battery of boats, RVs, SUVs, etc.
【Warranty】2-year limited material and workmanship warranty. 10-year 90% output warranty. 25-year 80% output warranty.
