XINPUGUANG Flexible Solar Panel 100W 12V Monocrystalline Solar Kit Hightweight Module, 10A Charge Controller,Extension Cable for RV Boat Cabin Car (100W-1)

Price: $119.90
(as of Jun 25, 2024 01:15:21 UTC – Details)

Product Description

XINPUGUANG flexible solar panel use monocrystalline cell with a conversion rate of 23%-24%. Flexible solar panel minimize area and weight while increasing module efficiency. It is the best choice for RV, rooftop, camper, trailer, boat, cabin, shed, tent, is perfect for outdoor applications.

Maximum power(Pmax) 100W Open circuit voltage(Voc) 23.04V Short circuit current(Isc) 5.55A Maximum power voltage(Vmp) 19.8V Maximum power current(Imp) 5.05A Maximum system voltage 700V DC Weight 4 lb Dimension 42.32X21.25X0.11 inchs Standard Test Conditions lrradiance 1000w/m2，Temperature 25℃,AM=1.5 Temperature range -40℃～+80℃

High Curvature

The solar panels can be bent up to 250 degrees, making them suitable for most curved surfaces.

Wear Resistance

Withstand up to 5400 Pa of heavy snow load and up to 2400 Pa of high wind load.

Waterproof

Junction box and cable adapter, IP67 waterproof rating. Suitable for outdoor installation.

High Efficiency

The solar panels are made of high-efficiency monocrystalline silicon cells with a conversion rate of up to 23%.

Related Products

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.1 out of 5 stars
110

3.9 out of 5 stars
31

4.0 out of 5 stars
129

4.3 out of 5 stars
3

3.6 out of 5 stars
7

Price

$189.90$189.90

$129.90$129.90

$139.90$139.90

$139.90$139.90

$79.90$79.90

Watts

200W

100W

100W

100W

100W

Supported Voltage

12V/24V

12V

12V

12V

12V

Mono

✔

✔

✔

✔

✔

Dimension

42.32X21.25X0.11 inchs

42.32X21.25X0.11 inchs

44.88X18.11X0.098 inch

44.88X18.11X0.098 inch

42.32X21.25X0.11 inchs

unit weight

3.9lb

3.9lb

4.0lb

4.0lb

3.9lb

*High Efficiency: solar panels use new Perc solar monocrystalline cells, up to 23% conversion rate, 100w solar panels are smaller, lighter and more portable
*Semi-Flexible: The plastic back sheet can be curved to a maximum 250 degree arc and mounted on RV, boat, cabin, tent, car, trucks, trailers or any other irregular surface.
*Thin & Lightweight：100W solar panel weighs approximately 4lb,Thickness is 0.1in, weighs 70% less than conventional solar panels, making transportation and installation a breeze.
*Practicality: Light energy converts electricity, Practical and suitable for use in areas where electricity is not available and where the city cannot reach, such as mountains, marine, deserts, and remote areas
*Nice Details: The component contains a bypass diode, and the circuit uses input over current protection and reverse protection design.The solar panel has 6 grommet mounting holes are available to attach fasteners，and can also be installed with silicone and adhesive tape.
